• 450W Compact Size 215.0 x 115.0 x 30.0mm
• Wide AC & DC Input 176V to 264VAC
• Temperature Range -30OC to +70OC
• LED Power Indicator
• Output Range: 12V – 48VDC
• Low Standby Power <0.5W
• Fully Isolated Pri – Sec: 4000Vrms
• Insulation: Class II
• Materials: UL94-V0
• UL/EN62368-1, EN61558, EN60335
• 3 Year Warranty
| Part Number | Power Rating | Output Voltage (VDC) | Output Current (mA) |
|---|---|---|---|
| VTX-212-450-012 | 450 | 12 | 37500 |
| VTX-212-450-015 | 450 | 15 | 30000 |
| VTX-212-450-024 | 451.2 | 24 | 18800 |
| VTX-212-450-027 | 450.9 | 27 | 16700 |
| VTX-212-450-036 | 450 | 36 | 12500 |
| VTX-212-450-048 | 451.2 | 48 | 9400 |
