• 10W Compact Size 55.0 x 45.0 x 22.0mm
• Wide AC & DC Input 85V to 305VAC (120 to 430VDC)
• Temperature Range -40OC to +85OC
• Dual Output
• I/O isolation test voltage 2500VAC 5mA 1min
• Internal Chip-on-Board (COB) Design
• High Flame-Retardant Housing
• Compliant with RoHS Directive
• Cooling Method: Natural Convection Cooling
• Excellent EMC shielding, output over-current protection, short-circuit protection.
| Part Number | Power Rating | Output 1 Voltage/ Current | Output 2 Volatge/ Current |
|---|---|---|---|
| VTX-214-010-405 | 10 | +5V/1000mA | -5V/1000mA |
| VTX-214-010-409 | 10 | +9/555mA | -9/555mA |
| VTX-214-010-412 | 10 | +12V/416mA | -12V/416mA |
| VTX-214-010-415 | 10 | +15V/333mA | -15V/333mA |
| VTX-214-010-424 | 10 | +24V/208mA | -24V/208mA |
| VTX-214-010-4505 | 10 | 5V | 5V/ customised |
| VTX-214-010-4512 | 10 | 5V | 12V/ customised |
| VTX-214-010-4524 | 10 | 5V | 24V/ customised |
