5 Watt Dual AC-DC Converter (4 Series)

Overview

• 10W Compact Size 48.50 x 36.00 x 20.50mm
• Wide AC & DC Input 85V to 264VAC (100 to 370VDC)
• Temperature Range -30OC to +70OC
• Dual Output
• Output Short Circuit,Overcurrent, OVC Protection
• Fully Isolated Pri – Sec >4000Vrms
• Insulation: Class I
• Materials: UL94-V0
• EMC performance meets CISPR32 RoHS / EN55032
CLASS B
• 3 Year Warranty

Datasheet

Description

Part NumberPower RatingOutput 1 Voltage/ CurrentOutput 2 Volatge/ Current
VTX-214-005-450555 V/ 900 mA5 V/ 100 mA
VTX-214-005-451255 V/ 750 mA12 V/ 100 mA
VTX-214-005-451555 V/ 700 mA15 V/ 100 mA
VTX-214-005-45245.45 V/ 600 mA24 V/ 100 mA
